Design
Number of fans: 1 fan(s)
Cooling type: Active
Product colour: Black
Fan diameter: 12 cm
On/off switch: Yes
Power
Power Good signal delay range: 100 - 500 ms
Total power: 750 W
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 120 W
Combined power (-12V): 3.6 W
Max output current (+12V): 62 A
Combined power (+12V): 744 W
AC input voltage: 220 - 240 V
Combined power (+5Vsb): 15 W
Max output current (-12V): 0.3 A
AC input frequency: 50/60 Hz
Efficiency: 88%
Hold time: 16 ms
Input current: 6 A
Max output current (+5V): 20 A
Max output current (+3.3V): 20 A
Max output current (+5Vsb): 3 A
Combined power (+5V): 120 W
Power protection features: Over power, Short circuit, Over voltage, Under voltage
Weight & dimensions
Height: 86 mm
Weight: 1.75 kg
Depth: 140 mm
Width: 150 mm
Performance
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Bearing technology: HDB
80 PLUS certification: 80 PLUS Bronze
Mean time between failures (MTBF): 100000 h
Packaging data
Package weight: 2.15 kg
Package width: 245 mm
Package depth: 190 mm
Package height: 110 mm
Package type: Box
Certificates
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE, China Compulsory Certification (CCC), EAC, UKCA, KC, TÜV mark, RCM, BIS
Ports & interfaces
EPS power connector (4+4 pin): Yes
Number of SATA power connectors: 6
Peripheral (Molex) power cable length: 400 mm, 700, 550
EPS power connector (8-pin): Yes
ATX Power connector (24-pin): Yes
SATA power cable length: 700, 400 mm, 550 mm
Cabling type: Non-Modular
PCI Express power connectors (6+2 pin): 4
Motherboard power cable length: 50 cm
Motherboard power connector: 24-pin ATX
Peripheral (Molex) power connectors (4-pin): 3
