Technical details
Sustainability certificates: ErP
Design
Fan location: Top
On/off switch: Yes
Fan diameter: 14 cm
Cooling type: Active
Product colour: Black
Power
Max output current (+5V): 20 A
Power Factor Correction (PFC) type: Active
Max output current (+5Vsb): 3 A
Hold time: 16 ms
Efficiency: 90%
Combined power (+3.3V): 120 W
Combined power (-12V): 3.6 W
Combined power (+5Vsb): 15 W
Total power: 1050 W
Combined power (+12V): 105 W
Power Good signal delay range: 100 - 150 ms
Power protection features: Overcharge, Short circuit, Over voltage, Over total voltage, Under voltage, Over power
Max output current (+12V): 87.5 A
Combined power (+5V): 120 W
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
AC input frequency: 50/60 Hz
Input current: 13 - 6 A
AC input voltage: 100 - 240 V
Weight & dimensions
Height: 86 mm
Depth: 180 mm
Width: 150 mm
Weight: 2.93 kg
Performance
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Bearing technology: FDB
Purpose: PC
ATX version: 3.1
Packaging data
Case or master carton dimensions (W x D x H): 325 x 620 x 220 mm
Package height: 122 mm
Package weight: 3.36 kg
Package type: Box
Package depth: 333 mm
Package width: 197 mm
Certificates
Compliance certificates: CCC, TÜV mark, CE, RCM, BIS, EAC, BSMI, cTUVus, UKCA, Federal Communications Commission (FCC)
Ports & interfaces
SATA power cable length: 860, 740, 500, 620
Peripheral (Molex) power cable length: 860 mm, 740, 500 mm, 620
Cabling type: Fully-Modular
Number of SATA power connectors: 12
PCI Express power connectors (6+2 pin): 3
Motherboard power cable length: 65 cm
EPS power connector (4+4 pin): Yes
Motherboard power connector: 24-pin ATX
PCI Express power connectors (12-pin): 1
ATX Power connector (24-pin): Yes
Peripheral (Molex) power connectors (4-pin): 4
EPS power connector (8-pin): Yes
