Design
Cooling type: Active
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Fan speed: 0 - 2400 RPM
Product colour: Black
Power
Combined power (-12V): 3.6 W
Power Factor Correction (PFC) type: Active
AC input frequency: 50/60 Hz
Power protection features: Under voltage, Over current, Short circuit, Over voltage, Overheating, Over power
Max output current (+12V): 54 A
Combined power (+5V): 120 W
Efficiency: 90%
Total power: 650 W
Power Good signal delay range: 100 - 150 ms
Hold time: 16 ms
Combined power (+12V): 648 W
Max output current (+3.3V): 20 A
Combined power (+3.3V): 120 W
Max output current (+5Vsb): 3 A
Max output current (+5V): 20 A
AC input voltage: 100 - 240 V
Max output current (-12V): 0.3 A
Combined power (+5Vsb): 15 W
Input current: 5 - 10 A
Operational conditions
Operating temperature (T-T): 0 - 40 °C
Weight & dimensions
Height: 86 mm
Depth: 140 mm
Weight: 1.7 kg
Width: 150 mm
Performance
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
ATX version: 3.1
Purpose: PC/Server
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Packaging data
Package width: 190 mm
Package depth: 260 mm
Package height: 110 mm
Package weight: 2.11 kg
Certification: ErP 2014 Lot 3
Certificates
Compliance certificates: EAC, RoHS, China Compulsory Certification (CCC), CCC, REACH, UKCA, cTUVus, RCM, BIS, BSMI, KC, Federal Communications Commission (FCC)
Ports & interfaces
Peripheral (Molex) power cable length: 700 mm, 550, 400
Cabling type: Non-Modular
Peripheral (Molex) power connectors (4-pin): 3
Motherboard power connector: 24-pin ATX
EPS power connector (8-pin): Yes
EPS power connector (4+4 pin): Yes
PCI Express connector: Yes
Motherboard power cable length: 50 cm
SATA power cable length: 550, 400, 700 mm
PCI Express power connectors (6+2 pin): 4
PCI Express power cable length: 62 cm
Number of SATA power connectors: 6
Number of EPS connectors: 2
Other features
EPS cable length: 67 cm
Logistics data
Master (outer) case length: 570 mm
Master (outer) case width: 275 mm
Master (outer) cases per pallet: 120 pc(s)
Master (outer) case height: 215 mm
