Technical details
Warranty period: 5 year(s)
Design
Number of fans: 2 fan(s)
Fins material: Aluminium
Base plate material: Copper
Radiator material: Aluminum
Fan connector: 4-pin
Product colour: Black
Power
Rated voltage: 12 V
Fan power consumption: 1.44 W
Safety current: 0.35 Ah
Rated current: 0.12 A
Weight & dimensions
Depth: 133 mm
Width: 114 mm
Height: 161 mm
Package width: 155 mm
Package height: 215 mm
Package depth: 155 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Maximum air pressure: 2.69 mmH2O
Suitable location: Processor
Fan speed (min): 0 RPM
Fan diameter: 12 cm
Quantity per pack: 1 pc(s)
Fan 2 maximum air pressure: 1.77 mmH2O
Fan 2 rotational speed (min): 0 RPM
Maximum airflow: 63.1 cfm
Fan 2 rotational speed (max): 1850 RPM
Fan 2 maximum airflow: 50.5 cfm
Airflow: 107.2 m³/h
Bearing type: Loop Dynamic Bearing (LDB)
Supported processor sockets: LGA 1150 (Socket H3), Socket AM5, LGA 1200 (Socket H5), LGA 1151 (Socket H4), LGA 1156 (Socket H), LGA 1700, LGA 1851, Socket AM4, LGA 1155 (Socket H2)
Pulse-width modulation (PWM) support: Yes
Fan noise level (max): 22.6 dB
Type: Air cooler
Fan noise level (min): 20 dB
Fan's mean time to failure (MTTF): 200000 h
Fan speed (max): 2050 RPM
Packaging content
Package type: Box
