Design Fan location: Top Cooling type: Active Product colour: Black On/off switch: Yes Number of fans: 1 fan(s) Fan diameter: 9.2 cm
Power Max output current (+5Vsb): 3 A Combined power (+12V): 1000 W Combined power (+3.3V): 130 W Max output current (+12V): 83.3 A Combined power (+5V): 130 W Max output current (+3.3V): 20 A Combined power (+5Vsb): 15 W Max output current (+5V): 20 A AC input voltage: 100 - 240 V Input current: 12-6 A Total power: 1000 W AC input frequency: 47 - 63 Hz
Weight & dimensions Weight: 2.3 kg
Performance Bearing technology: FDB Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: SFX 80 PLUS certification: 80 PLUS Platinum Purpose: PC ATX version: 3.1 Silent mode: Yes
Packaging data Package type: Box
Packaging content Cables included: AC, CPU, PATA, PCIe, SATA
Ports & interfaces Number of SATA power connectors: 3 SATA power cable length: 445 mm Motherboard power cable length: 30 cm Number of PATA power connectors: 1 EPS power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX PCI Express power cable length: 40 cm Cabling type: Fully-Modular PCI Express power connectors (6+2 pin): 4
