Design Product colour: Black Fan diameter: 14 cm Cooling type: Active On/off switch: Yes Number of fans: 1 fan(s)
Power Max output current (+5V): 20 A Combined power (+12V): 1000 W Max output current (+5Vsb): 3 A AC input voltage: 100 - 240 V Input current: 13 - 6.5 A Combined power (+5Vsb): 15 W AC input frequency: 47 - 63 Hz Combined power (+5V): 150 W Total power: 1000 W Combined power (+3.3V): 150 W Max output current (+3.3V): 25 A Max output current (+12V): 83.3 A
Weight & dimensions Depth: 150 mm Height: 86 mm Weight: 3.56 kg Width: 180 mm
Performance 80 PLUS certification: 80 PLUS Platinum Mean time between failures (MTBF): 100000 h ATX version: 3.1 Power supply unit (PSU) form factor: ATX Bearing technology: FDB Purpose: PC
Ports & interfaces Number of PATA power connectors: 8 Number of SATA power connectors: 8 ATX Power connector (24-pin): Yes Motherboard power cable length: 61 cm SATA power cable length: 445 mm, 155 mm Motherboard power connector: 24-pin ATX PCI Express connector: Yes Cabling type: Fully-Modular
