Design Cooling type: Active Product colour: Black On/off switch: Yes Fan diameter: 14 cm Number of fans: 1 fan(s)
Power Input current: 15 - 7.5 A AC input voltage: 100 - 240 V AC input frequency: 47 - 63 Hz Max output current (+12V): 100 A Max output current (+5Vsb): 3 A Combined power (+12V): 1500 W Combined power (+5Vsb): 15 W Total power: 1200 W Combined power (+5V): 150 W Max output current (+5V): 25 A Max output current (+3.3V): 25 A Combined power (+3.3V): 150 W
Weight & dimensions Depth: 150 mm Weight: 3.98 kg Height: 86 mm Width: 200 mm
Performance Bearing technology: FDB 80 PLUS certification: 80 PLUS Platinum ATX version: 3.1 Purpose: PC Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h
Ports & interfaces PCI Express connector: Yes Number of SATA power connectors: 8 Motherboard power connector: 24-pin ATX Number of PATA power connectors: 8 SATA power cable length: 445 mm ATX Power connector (24-pin): Yes Motherboard power cable length: 61 cm Cabling type: Fully-Modular
