Design Number of fans: 1 fan(s) Cooling type: Active Fan diameter: 14 cm On/off switch: Yes Product colour: Black
Power Input current: 15 - 9 A Max output current (+5V): 20 A AC input voltage: 100 - 240 V Combined power (+5Vsb): 17.5 W AC input frequency: 47 - 63 Hz Total power: 1500 W Max output current (+12V): 125 A Combined power (+3.3V): 150 W Max output current (+5Vsb): 3.5 A Combined power (+5V): 150 W Max output current (+3.3V): 25 A Combined power (+12V): 1500 W
Weight & dimensions Depth: 150 mm Weight: 4.35 kg Height: 86 mm Width: 200 mm
Performance ATX version: 3.1 Bearing technology: FDB Purpose: PC 80 PLUS certification: 80 PLUS Platinum Mean time between failures (MTBF): 100000 h Power supply unit (PSU) form factor: ATX
Ports & interfaces ATX Power connector (24-pin): Yes Motherboard power connector: 24-pin ATX SATA power cable length: 445 mm Motherboard power cable length: 61 cm Number of PATA power connectors: 8 Cabling type: Fully-Modular Number of SATA power connectors: 12 PCI Express connector: Yes
