Design Cooling type: Active Fan diameter: 12 cm Fan location: Front Number of fans: 1 fan(s) On/off switch: Yes Product colour: Black
Power Max output current (+12V): 54.2 A Combined power (+5Vsb): 15 W Max output current (+5Vsb): 3 A Combined power (+3.3V): 110 W Total power: 650 W Max output current (+5V): 20 A Combined power (+12V): 650 W Combined power (+5V): 110 W Max output current (+3.3V): 20 A Input current: 10 - 5 A AC input voltage: 100 - 240 V AC input frequency: 47 - 63 Hz
Weight & dimensions Height: 150 mm Width: 140 mm Depth: 86 mm Weight: 2.73 kg
Performance ATX version: 3.1 Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Gold Purpose: PC Mean time between failures (MTBF): 100000 h Bearing technology: Rifle
Ports & interfaces ATX Power connector (24-pin): Yes Cabling type: Fully-Modular PCI Express connector: Yes ATX power connector (12+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Number of PATA power connectors: 2 Number of SATA power connectors: 6 CPU power connector (4+4 pin): Yes Motherboard power connector: 24-pin ATX
