Design On/off switch: Yes Product colour: Black Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 14 cm
Power AC input frequency: 47 - 63 Hz AC input voltage: 100 - 240 V Input current: 12 - 5 A Total power: 1000 W Max output current (+12V): 83.3 A Combined power (+3.3V): 150 W Max output current (+5Vsb): 3 A Maximum input current (@220V): 5 A Combined power (-12V): 9.6 W Maximum input current (@110V): 12 A Combined power (+12V): 1000 W Max output current (+3.3V): 25 A Combined power (+5V): 150 W Max output current (-12V): 0.8 A Combined power (+5Vsb): 15 W Max output current (+5V): 25 A
Weight & dimensions Depth: 160 mm Height: 86 mm Width: 150 mm Weight: 3.65 kg
Performance Purpose: PC Bearing technology: Rifle EPS version: 2.92 Power supply unit (PSU) form factor: ATX 80 PLUS certification: 80 PLUS Gold ATX version: 2.4 Mean time between failures (MTBF): 100000 h
Packaging data Package type: Box
Certificates Compliance certificates: RoHS
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 12 EPS power connector (8-pin): Yes Cabling type: Fully-Modular Motherboard power connector: 24-pin ATX Number of SATA power connectors: 11 Floppy drive power connector: 1 PCI Express connector: Yes
