Design Product colour: Black Fan diameter: 14 cm Cooling type: Active Number of fans: 1 fan(s) On/off switch: Yes
Power Max output current (+12V): 62.5 A Combined power (+3.3V): 150 W Max output current (+5Vsb): 3 A Maximum input current (@220V): 5 A Max output current (-12V): 0.8 A Combined power (-12V): 9.6 W Combined power (+12V): 750 W Combined power (+5V): 150 W Total power: 750 W Maximum input current (@110V): 10 A Input current: 10 - 5 A AC input voltage: 100 - 240 V Combined power (+5Vsb): 15 W AC input frequency: 47 - 63 Hz Max output current (+5V): 25 A Max output current (+3.3V): 25 A
Weight & dimensions Height: 86 mm Depth: 160 mm Width: 150 mm Weight: 3.19 kg
Performance Power supply unit (PSU) form factor: ATX EPS version: 2.92 ATX version: 2.4 Bearing technology: Rifle Purpose: PC Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold
Packaging data Package type: Box
Certificates Compliance certificates: RoHS
Ports & interfaces EPS power connector (8-pin): Yes Peripheral (Molex) power connectors (4-pin): 7 Motherboard power connector: 24-pin ATX Number of SATA power connectors: 8 PCI Express connector: Yes Cabling type: Fully-Modular Floppy drive power connector: 1
