Design Product colour: Black Fan location: Front Illumination: No Cooling type: Active Number of fans: 1 fan(s) On/off switch: Yes Fan diameter: 12 cm
Power AC input voltage: 100 - 240 V Combined power (+5Vsb): 15 W Max output current (+3.3V): 20 A Input current: 10 - 5 A Max output current (+12V): 62.5 A Combined power (+5V): 150 W Combined power (+3.3V): 150 W Max output current (+5Vsb): 3 A Max output current (+5V): 20 A Combined power (+12V): 1000 W Total power: 1000 W AC input frequency: 47 - 63 Hz
Weight & dimensions Width: 150 mm Depth: 86 mm Weight: 3.23 kg Height: 140 mm
Performance Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1
Ports & interfaces Number of SATA power connectors: 6 EPS power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Cabling type: Fully-Modular Number of PATA power connectors: 2 Motherboard power connector: 24-pin ATX PCI Express power connectors (12+4 pin): 1
