Design
Cooling type: Active
Fan diameter: 14 cm
Number of fans: 1 fan(s)
Product colour: Black
Power
Power protection features: Over current, Short circuit, Over voltage, Overheating, Over power
Max output current (+5Vsb): 3 A
Efficiency: 90%
Total power: 850 W
Combined power (+5V): 150 W
Combined power (+3.3V): 150 W
Max output current (+3.3V): 20 A
Max output current (+12V): 70.8 A
Combined power (+5Vsb): 15 W
Combined power (+12V): 849.6 W
Max output current (+5V): 20 A
AC input frequency: 47 - 63 Hz
AC input voltage: 100 - 240 V
Input current: 10 - 5 A
Weight & dimensions
Height: 86 mm
Depth: 160 mm
Width: 150 mm
Weight: 3.28 kg
Performance
Purpose: PC/Server
Power supply unit (PSU) form factor: ATX
EPS version: 2.92
80 PLUS certification: 80 PLUS Gold
ATX version: 3.0
Packaging content
Cable tie(s) included: Yes
Cables included: AC, DC
Certificates
Compliance certificates: Low Voltage Directive (LVD), UKCA, RoHS
Ports & interfaces
SATA power cable length: 570, 800 mm, 455, 685
Peripheral (Molex) power cable length: 750, 550, 450 mm, 650
Cabling type: Fully-Modular
Number of SATA power connectors: 12
Motherboard power connector: 24-pin ATX
Motherboard power cable length: 61 cm
EPS power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 3
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power cable length: 75 cm
PCI Express power connectors (16-pin): 1
