Design Cooling type: Active Number of fans: 1 fan(s) On/off switch: Yes Fan diameter: 14 cm Product colour: Black
Power Combined power (+12V): 1000 W Max output current (+3.3V): 20 A Combined power (+5V): 120 W Combined power (+3.3V): 120 W Max output current (+12V): 83.2 A Max output current (+5V): 20 A Combined power (+5Vsb): 15 W AC input voltage: 100 - 240 V AC input frequency: 47 - 63 Hz Total power: 1000 W Max output current (+5Vsb): 3 A
Weight & dimensions Width: 160 mm Weight: 3.1 kg Depth: 150 mm Height: 86 mm
Performance Mean time between failures (MTBF): 100000 h ATX version: 3.1 Purpose: PC 80 PLUS certification: 80 PLUS Gold Bearing technology: FDB Power supply unit (PSU) form factor: ATX
Ports & interfaces PCI Express connector: Yes SATA power cable length: 500 mm, 100, 700 mm EPS power connector (8-pin): Yes Number of PATA power connectors: 4 Motherboard power cable length: 61 cm PCI Express power connectors (6+2 pin): 2 Cabling type: Fully-Modular Motherboard power connector: 24-pin ATX ATX Power connector (24-pin): Yes Number of SATA power connectors: 12 PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (12+4 pin) cable length: 650 mm
