Technical details
Compliance certificates: CE
Design
Product colour: Black
Number of heat pipes: 6
Fan connector: 4-pin
Base plate material: Copper
Illumination LED: Yes
Illumination colour: Multi
Number of fan blades: 9
LED connector type: 3-pin
Number of fans: 1 fan(s)
Power
Rated current: 0.23 A
Fan voltage: 12 V
Fan power consumption: 2.76 W
Weight & dimensions
Weight: 1.15 kg
Package weight: 1.65 kg
Cable length: 200 m
Package height: 188 mm
Depth: 135 mm
Width: 110 mm
Height: 160 mm
Package width: 180 mm
Heat pipes diameter: 6 mm
Package depth: 180 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Performance
Type: Air cooler
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, Socket FM1, LGA 1366 (Socket B), LGA 1155 (Socket H2), Socket AM3, LGA 1151 (Socket H4), Socket AM2+, Socket FM2, Socket AM4, LGA 2011 (Socket R), Socket AM3+, LGA 2066, LGA 1150 (Socket H3), Socket AM5, LGA 1200 (Socket H5), Socket AM2
Airflow: 143.53 m³/h
Maximum air pressure: 4.24 mmH2O
Fan speed (min): 600 RPM
Maximum airflow: 82.48 cfm
Noise level (high speed): 31.68 dB
Fan bearing technology: Hydro Dynamic Bearing (HDB)
Suitable location: Processor
Fan speed (max): 2000 RPM
Packaging content
Package type: Box
Other features
Country of origin: China
