Design
Product colour: Black
Fan connector: 4-pin
Number of fan blades: 9
Number of fans: 1 fan(s)
Number of heat pipes: 6
Power
Power consumption (typical): 3.36 W
Rated voltage: 12 V
Rated current: 0.28 A
Weight & dimensions
Radiator height: 16 cm
Cable length: 0.2 m
Package width: 180 mm
Heat pipes diameter: 6 mm
Radiator depth: 13.5 cm
Package depth: 180 mm
Weight: 1.13 kg
Package height: 188 mm
Depth: 135 mm
Width: 110 mm
Radiator width: 8.5 cm
Package weight: 1.51 kg
Height: 160 mm
Performance
Maximum airflow: 82.48 cfm
Quantity per pack: 1 pc(s)
Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Maximum air pressure: 4.24 mmH2O
Airflow: 143.53 m³/h
Suitable location: Processor
Supported processor sockets: Socket AM4, Socket AM3+, LGA 1200 (Socket H5), LGA 1151 (Socket H4), Socket AM2+, LGA 1156 (Socket H), LGA 1700, Socket FM2, LGA 1155 (Socket H2), Socket AM3, LGA 1366 (Socket B), LGA 1150 (Socket H3), Socket AM5, LGA 2066, Socket FM1, Socket AM2
Fan bearing technology: Hydraulic bearing
Fan diameter: 12 cm
Type: Heatsink/Radiator
Pulse-width modulation (PWM) support: Yes
Fan noise level (max): 34.5 dB
Packaging content
Package type: Box
