Technical details
Compliance certificates: Federal Communications Commission (FCC), RoHS, CE
Warranty period: 5 year(s)
Design
Material: Metal
Number of fans: 2 fan(s)
Product colour: Black
Base plate material: Copper
Fan connector: 4-pin
Number of fan blades: 9
Illumination colour: Multi
Water block material: Copper
Radiator material: Aluminum
Illumination LED: Yes
LED connector type: 3-pin
Power
Rated current: 0.23 A
Pump power consumption: 4.2 W
LED voltage: 5 V
Fan power consumption: 2.76 W
Fan voltage: 12 V
Pump current: 350 mA
Pump voltage: 12 V
Rated voltage: 12 V
Fan current: 0.23 A
Weight & dimensions
Package width: 211.5 mm
Height: 27 mm
Package weight: 2.08 kg
Depth: 120 mm
Width: 274 mm
Package height: 143 mm
Weight: 847 g
Package depth: 350 mm
Waterblock depth: 7.15 cm
Waterblock height: 4.98 cm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Radiator depth: 12.1 cm
Radiator width: 27.2 cm
Tube length: 40 cm
Radiator height: 2.7 cm
Waterblock width: 7.15 cm
Performance
Supported processor sockets: Socket TR4, LGA 1200 (Socket H5), LGA 1156 (Socket H), LGA 1700, Socket AM2, Socket FM1, LGA 1150 (Socket H3), Socket AM5, LGA 1155 (Socket H2), Socket AM3, LGA 1366 (Socket B), LGA 1151 (Socket H4), Socket AM2+, LGA 2066, LGA 2011 (Socket R), Socket AM3+, Socket AM4, Socket FM2
Type: All-in-one liquid cooler
Fan diameter: 12 cm
Quantity per pack: 1 pc(s)
Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i5, Intel® Core™ i3
Maximum airflow: 82.48 cfm
Fan speed (max): 2000 RPM
Fan speed (min): 600 RPM
Pulse-width modulation (PWM) support: Yes
Pump motor speed: 3200 RPM
Fan noise level (max): 34.5 dB
Maximum air pressure: 4.24 mmH2O
Pump connector: 3-pin
Suitable location: Computer case
Packaging content
Cables included: Fan
Mounting kit: Yes
Package type: Box
Screws included: Yes
RGB controller included: Yes
Installation instruction: Yes
CPU bracket(s): Yes
Other features
Country of origin: China
