Design
Illumination LED: Yes
Fan connector: 4-pin
Radiator material: Aluminum
Product colour: White
Number of fans: 2 fan(s)
Base plate material: Copper
Illumination colour: Multi
LED connector type: 3-pin
Power
Fan voltage: 12 V
Pump power consumption: 2.76 W
LED voltage: 5 V
Fan current: 0.37 A
Fan power consumption: 4.44 W
Rated voltage: 12 V
Rated current: 0.37 A
Pump voltage: 12 DC
Pump current: 230 mA
LED power consumption (fan): 1.75 W
Weight & dimensions
Height: 27 mm
Package depth: 337 mm
Package weight: 2 kg
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Radiator width: 27.7 cm
Weight: 773 g
Radiator height: 2.7 cm
Package width: 240 mm
Radiator depth: 12 cm
Depth: 277 mm
Width: 120 mm
Waterblock depth: 7.1 cm
Waterblock height: 6.8 cm
Tube length: 40 cm
Package height: 139 mm
Waterblock width: 8.35 cm
Performance
Maximum air pressure: 3.26 mmH2O
Pulse-width modulation (PWM) support: Yes
Fan diameter: 12 cm
Quantity per pack: 1 pc(s)
Rotational speed (min): 500 RPM
Pump motor speed: 3000 RPM
Type: All-in-one liquid cooler
Noise level (high speed): 32.1 dB
Maximum airflow: 64.95 cfm
Suitable location: Processor
Rotational speed (max): 2200 RPM
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, Socket FM2, LGA 1155 (Socket H2), Socket AM3, LGA 1151 (Socket H4), LGA 1200 (Socket H5), LGA 1851, Socket AM4, LGA 1150 (Socket H3), Socket AM5, Socket AM2, Socket FM1
Pump connector: 3-pin
