Design
Illumination colour: Multi
Number of fans: 3 fan(s)
Illumination LED: Yes
Fan connector: 4-pin
Product colour: White
LED connector type: 3-pin
Radiator material: Aluminum
Base plate material: Copper
Power
LED power consumption (fan): 1.75 W
Rated current: 0.37 A
Fan power consumption: 4.44 W
Pump current: 230 mA
Pump power consumption: 2.76 W
Fan voltage: 12 V
LED voltage: 5 V
Pump voltage: 12 DC
Rated voltage: 12 V
Fan current: 0.37 A
Weight & dimensions
Package width: 437 mm
Package height: 139 mm
Width: 120 mm
Height: 27 mm
Package weight: 2.5 kg
Weight: 830 g
Depth: 394 mm
Package depth: 275 mm
Fan dimensions (W x D x H): 120 x 120 x 25 mm
Waterblock height: 6.8 cm
Radiator depth: 12 cm
Radiator width: 39.4 cm
Tube length: 40 cm
Waterblock depth: 7.1 cm
Radiator height: 2.7 cm
Waterblock width: 8.35 cm
Performance
Pulse-width modulation (PWM) support: Yes
Supported processor sockets: LGA 1156 (Socket H), LGA 1700, Socket AM4, LGA 1200 (Socket H5), Socket FM1, LGA 1851, LGA 1150 (Socket H3), Socket AM5, LGA 1151 (Socket H4), Socket AM2, LGA 1155 (Socket H2), Socket AM3, Socket FM2
Noise level (high speed): 32.1 dB
Rotational speed (max): 2200 RPM
Quantity per pack: 1 pc(s)
Fan diameter: 12 cm
Rotational speed (min): 500 RPM
Maximum airflow: 64.95 cfm
Type: All-in-one liquid cooler
Maximum air pressure: 3.26 mmH2O
Pump motor speed: 3000 RPM
Pump connector: 3-pin
Suitable location: Processor
