Design
Number of fans: 2 fan(s)
Illumination LED: Yes
Illumination colour: Multi
LED connector type: 3-pin
Fan connector: 4-pin
Product colour: White
Radiator material: Aluminum
Power
LED power consumption (fan): 5 W
Pump voltage: 12 DC
Rated voltage: 12 V
Pump power consumption: 2.4 W
Fan current: 0.56 A
Fan power consumption: 6.72 W
LED voltage: 5 V
Pump current: 200 mA
Weight & dimensions
Package weight: 1.8 kg
Package height: 143 mm
Package depth: 222 mm
Fan dimensions (W x D x H): 243.6 x 125 x 25 mm
Package width: 350 mm
Radiator height: 2.7 cm
Waterblock width: 7 cm
Tube length: 39 cm
Waterblock height: 5.9 cm
Radiator depth: 12.1 cm
Waterblock depth: 7 cm
Radiator width: 27.2 cm
Performance
Rotational speed (min): 700 RPM
Fan diameter: 12 cm
Maximum air pressure: 5.4 mmH2O
Maximum airflow: 78.2 cfm
Supported processor sockets: LGA 1151 (Socket H4), Socket FM2, LGA 1200 (Socket H5), LGA 1155 (Socket H2), Socket AM3, Socket FM1, LGA 1851, LGA 1156 (Socket H), LGA 1700, LGA 1150 (Socket H3), Socket AM5, Socket AM4
Rotational speed (max): 2500 RPM
Noise level (high speed): 38 dB
Type: All-in-one liquid cooler
Pulse-width modulation (PWM) support: Yes
Pump motor speed: 2700 RPM
Suitable location: Processor
Pump connector: 3-pin
