Design
Number of fans: 1 fan(s)
On/off switch: Yes
Fan diameter: 13.5 cm
Cooling type: Active
Product colour: Silver
Power
Power protection features: Short circuit, Overheating, Over power, Under voltage, Over current, Over voltage
Max output current (+3.3V): 20 A
Max output current (-12V): 0.3 A
Total power: 1050 W
Combined power (-12V): 3.6 W
AC input frequency: 47 - 63 Hz
Max output current (+12V): 87.5 A
Max output current (+5Vsb): 3 A
Combined power (+12V): 1050 W
Combined power (+5V): 100 W
Combined power (+3.3V): 100 W
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Input current: 15 - 7 A
Max output current (+5V): 20 A
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 20 - 85%
Operating temperature (T-T): 10 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Width: 150 mm
Depth: 180 mm
Height: 86 mm
Weight: 2.1 kg
Performance
Bearing technology: HDB
ATX version: 3.1
Purpose: PC
80 PLUS certification: 80 PLUS Platinum
Mean time between failures (MTBF): 100000 h
Power supply unit (PSU) form factor: ATX
Packaging data
Package width: 229 mm
Package height: 107 mm
Package type: Box
Package weight: 3.59 kg
Package depth: 331 mm
Certificates
Compliance certificates: EAC, CCC, Federal Communications Commission (FCC), RoHS, CE, TÜV mark
Ports & interfaces
PCI Express power connectors (12-pin): 1
Peripheral (Molex) power cable length: 500 mm, 120 mm
CPU power cable length: 65 cm
Motherboard power cable length: 65 cm
EPS power connector (8-pin): Yes
Cabling type: Fully-Modular
ATX power connector (20+4 pin): Yes
CPU power connector (4+4 pin): Yes
PCI Express connector: Yes
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 120, 500
Number of PATA power connectors: 4
PCI Express power connectors (6+2 pin): 7
Number of SATA power connectors: 12
PCI Express power cable length: 65 cm
Peripheral (Molex) power connectors (4-pin): 4
PCI Express power connectors (12+4 pin) cable length: 650 mm
