Design
Fan diameter: 13.5 cm
Product colour: Silver
Power
Combined power (-12V): 3.6 W
AC input frequency: 47 - 63 Hz
Combined power (+3.3V): 100 W
Max output current (+12V): 100 A
Power protection features: Over power, Short circuit, Over voltage, Overheating, Under voltage, Over current
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
Max output current (+5Vsb): 3 A
Combined power (+12V): 1200 W
Max output current (+5V): 20 A
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Total power: 1200 W
Efficiency: 92%
Input current: 15 - 7 A
Max output current (-12V): 0.3 A
Weight & dimensions
Depth: 150 mm
Height: 86 mm
Weight: 2.09 kg
Width: 180 mm
Performance
80 PLUS certification: 80 PLUS Platinum
Mean time between failures (MTBF): 100000 h
Purpose: PC
Silent mode: Yes
Packaging data
Package depth: 229 mm
Package width: 331 mm
Package weight: 3.59 kg
Package height: 107 mm
Packaging content
Cables included: CPU, PATA, PCIe, SATA
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
PCI Express power connectors (6+2 pin): 9
Peripheral (Molex) power connectors (4-pin): 4
Cabling type: Fully-Modular
Number of SATA power connectors: 12
CPU power connector (4+4 pin): Yes
