Design
Product colour: Silver
On/off switch: Yes
Cooling type: Active
Number of fans: 1 fan(s)
Fan diameter: 13.5 cm
Power
Combined power (+12V): 1050 W
Max output current (+5V): 20 A
Max output current (+5Vsb): 3 A
Efficiency: 90%
Combined power (-12V): 3.6 W
Combined power (+3.3V): 100 W
Combined power (+5Vsb): 15 W
AC input voltage: 100 - 240 V
Total power: 1050 W
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
Max output current (+12V): 87.5 A
Input current: 15 - 7 A
Max output current (+3.3V): 20 A
Combined power (+5V): 100 W
AC input frequency: 47 - 63 Hz
Max output current (-12V): 0.3 A
Operational conditions
Operating temperature (T-T): 10 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 20 - 85%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Height: 86 mm
Depth: 180 mm
Weight: 2.09 kg
Width: 150 mm
Performance
Bearing technology: HDB
Mean time between failures (MTBF): 100000 h
Noise level: 22 dB
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Platinum
Purpose: PC
ATX version: 3.1
Silent mode: Yes
Packaging data
Package type: Box
Package width: 229 mm
Package height: 107 mm
Package depth: 331 mm
Package weight: 3.59 kg
Certificates
Compliance certificates: RoHS, TÜV mark, Federal Communications Commission (FCC), CCC, CE, EAC
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 4
EPS power connector (8-pin): Yes
Cabling type: Fully-Modular
Motherboard power cable length: 65 cm
PCI Express power connectors (6+2 pin): 6
SATA power cable length: 120, 500
Motherboard power connector: 20+4 pin ATX
CPU power cable length: 65 cm
Number of PATA power connectors: 4
Peripheral (Molex) power cable length: 500 mm, 120 mm
CPU power connector (4+4 pin): Yes
PCI Express connector: Yes
Number of SATA power connectors: 12
PCI Express power connectors (8-pin): 1
ATX power connector (20+4 pin): Yes
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 650 mm
Logistics data
Country of origin: China
