Design
Fan connector: 4-pin
Number of fans: 2 fan(s)
Radiator material: Aluminum
Illumination colour: Multi
Product colour: Black
Illumination LED: Yes
LED connector type: 3-pin
Power
Pump power consumption: 2.4 W
Pump current: 200 mA
Fan power consumption: 6.72 W
Fan current: 0.56 A
Pump voltage: 12 DC
Rated voltage: 12 V
LED voltage: 5 V
LED power consumption (fan): 5 W
Weight & dimensions
Waterblock height: 5.9 cm
Tube length: 39 cm
Radiator width: 27.2 cm
Waterblock width: 7 cm
Radiator height: 2.7 cm
Package depth: 222 mm
Fan dimensions (W x D x H): 243.6 x 125 x 25 mm
Waterblock depth: 7 cm
Radiator depth: 12.1 cm
Package height: 143 mm
Package weight: 1.8 kg
Package width: 350 mm
Performance
Supported processor sockets: LGA 1151 (Socket H4), LGA 1155 (Socket H2), Socket AM3, LGA 1150 (Socket H3), LGA 1156 (Socket H), Socket FM2, Socket AM5, LGA 1700, LGA 1851, LGA 1200 (Socket H5), Socket AM4, Socket FM1
Fan diameter: 12 cm
Suitable location: Processor
Pump motor speed: 2700 RPM
Maximum air pressure: 5.4 mmH2O
Pump connector: 3-pin
Maximum airflow: 78.2 cfm
Type: All-in-one liquid cooler
Rotational speed (max): 2500 RPM
Pulse-width modulation (PWM) support: Yes
Rotational speed (min): 700 RPM
Noise level (high speed): 38 dB
