Design
On/off switch: Yes
Product colour: Black
Cooling type: Active
Fan location: Top
Number of fans: 1 fan(s)
Fan diameter: 12 cm
Power
AC input frequency: 50/60 Hz
Efficiency: 87%
Input current: 10 - 5 A
AC input voltage: 100 - 240 V
Max output current (+5Vsb): 3 A
Combined power (+5Vsb): 15 W
Power protection features: Over power, Overheating, Short circuit, Over voltage, Under voltage, Over current
Combined power (+12V): 528 W
Max output current (+5V): 20 A
Max output current (-12V): 0.3 A
Combined power (-12V): 3.6 W
Max output current (+3.3V): 24 A
Combined power (+3.3V): 120 W
Combined power (+5V): 120 W
Total power: 550 W
Max output current (+12V): 44 A
Weight & dimensions
Depth: 140 mm
Weight: 1.55 kg
Width: 150 mm
Height: 86 mm
Performance
Purpose: PC/Server
80 PLUS certification: 80 PLUS Bronze
Packaging data
Package width: 158 mm
Package type: Box
Package height: 165 mm
Package depth: 187 mm
Package weight: 1.85 kg
Certificates
Compliance certificates: EAC, Federal Communications Commission (FCC), CCC, RoHS, CE
Ports & interfaces
Number of PATA power connectors: 2
PCI Express power cable length: 55 cm
SATA power cable length: 150, 450
Motherboard power cable length: 50 cm
CPU power cable length: 70 cm
Cabling type: Non-Modular
Number of SATA power connectors: 6
CPU power connector (4+4 pin): Yes
PCI Express power connectors (6+2 pin): 2
PCI Express connector: Yes
Motherboard power connector: 20+4 pin ATX
