Design On/off switch: Yes Fan diameter: 12 cm Cooling type: Active Number of fans: 1 fan(s) Product colour: Black
Power Max output current (+5Vsb): 3 A Combined power (+5Vsb): 15 W Efficiency: 87% Max output current (+5V): 20 A AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Input current: 10-6 A Combined power (-12V): 3.6 W Combined power (+12V): 649.2 W Max output current (-12V): 0.3 A Max output current (+12V): 54.1 A Power protection features: Over current, Overheating, Over power, Short circuit, Over voltage, Under total voltage Total power: 650 W Combined power (+5V): 130 W Max output current (+3.3V): 20 A Combined power (+3.3V): 130 W Power Factor Correction (PFC) type: Active
Weight & dimensions Depth: 150 mm Width: 140 mm Height: 86 mm Weight: 1.8 kg
Performance Bearing technology: Rifle Purpose: PC 80 PLUS certification: 80 PLUS Bronze ATX version: 3.1 Power supply unit (PSU) form factor: ATX
Packaging data Package height: 165 mm Package weight: 2.05 kg Package width: 187 mm Package depth: 158 mm
Ports & interfaces PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 6 CPU power cable length: 70 cm SATA power cable length: 450, 150 Cabling type: Non-Modular Motherboard power connector: 24-pin ATX Motherboard power cable length: 55 cm PCI Express power connectors (12+4 pin): 1 CPU power connector (4+4 pin): Yes PCI Express power connectors (12+4 pin) cable length: 600 mm
