Design Cooling type: Active Product colour: Black On/off switch: Yes Number of fans: 1 fan(s) Fan diameter: 12 cm
Power Combined power (+5Vsb): 15 W Max output current (+5V): 22 A AC input frequency: 50/60 Hz Max output current (-12V): 0.3 A Combined power (-12V): 3.6 W AC input voltage: 100 - 240 V Input current: 10-6 A Power protection features: Over power, Overheating, Short circuit, Over voltage, Under total voltage, Over current Combined power (+12V): 750 W Max output current (+3.3V): 22 A Total power: 750 W Power Factor Correction (PFC) type: Active Combined power (+5V): 140 W Combined power (+3.3V): 140 W Max output current (+12V): 62.5 A Efficiency: 87% Max output current (+5Vsb): 3 A
Weight & dimensions Width: 140 mm Weight: 1.94 kg Height: 86 mm Depth: 150 mm
Performance 80 PLUS certification: 80 PLUS Bronze Bearing technology: Rifle Power supply unit (PSU) form factor: ATX Purpose: PC ATX version: 3.1
Packaging data Package height: 165 mm Package weight: 2.23 kg Package width: 187 mm Package depth: 158 mm
Ports & interfaces PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (12+4 pin) cable length: 600 mm Cabling type: Non-Modular Motherboard power cable length: 55 cm CPU power cable length: 70 cm Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 4 SATA power cable length: 450, 150 Motherboard power connector: 24-pin ATX CPU power connector (4+4 pin): Yes Number of SATA power connectors: 6
