COUGAR Power Supply ATLAS 750W ATX3.1 /80 Plus Bronze

(ocijenilo: 0 korisnik/a)

Šifra: 28-WLONONWCRPNMO | Brand: COUGAR

87,00 €
  • Dostupno za narudžbu, isporuka unutar 3 do 14 radnih dana
  • Mogućnost plaćanja na rate
    Već od 2,62 €/mj. ℹ️
  • Cijena dostave za ovaj artikl je 6,00 €
Design
Cooling type: Active
Product colour: Black
On/off switch: Yes
Number of fans: 1 fan(s)
Fan diameter: 12 cm

Power
Combined power (+5Vsb): 15 W
Max output current (+5V): 22 A
AC input frequency: 50/60 Hz
Max output current (-12V): 0.3 A
Combined power (-12V): 3.6 W
AC input voltage: 100 - 240 V
Input current: 10-6 A
Power protection features: Over power, Overheating, Short circuit, Over voltage, Under total voltage, Over current
Combined power (+12V): 750 W
Max output current (+3.3V): 22 A
Total power: 750 W
Power Factor Correction (PFC) type: Active
Combined power (+5V): 140 W
Combined power (+3.3V): 140 W
Max output current (+12V): 62.5 A
Efficiency: 87%
Max output current (+5Vsb): 3 A

Weight & dimensions
Width: 140 mm
Weight: 1.94 kg
Height: 86 mm
Depth: 150 mm

Performance
80 PLUS certification: 80 PLUS Bronze
Bearing technology: Rifle
Power supply unit (PSU) form factor: ATX
Purpose: PC
ATX version: 3.1

Packaging data
Package height: 165 mm
Package weight: 2.23 kg
Package width: 187 mm
Package depth: 158 mm

Ports & interfaces
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 600 mm
Cabling type: Non-Modular
Motherboard power cable length: 55 cm
CPU power cable length: 70 cm
Peripheral (Molex) power connectors (4-pin): 2
PCI Express power connectors (6+2 pin): 4
SATA power cable length: 450, 150
Motherboard power connector: 24-pin ATX
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 6
