Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
Cooling type: Active
Fan location: Top
On/off switch: Yes
Product colour: Black
Power
Input current: 12 - 6 A
AC input voltage: 100 - 240 V
Power protection features: Overheating, Under voltage, Over current, Short circuit, Over voltage, Over power
AC input frequency: 50 - 60 Hz
Total power: 850 W
Efficiency: 91%
Combined power (+12V): 849.6 W
Combined power (+3.3V): 120 W
Combined power (+5V): 120 W
Max output current (+5Vsb): 3 A
Max output current (+3.3V): 20 A
Max output current (+12V): 70.8 A
Max output current (-12V): 0.3 A
Combined power (-12V): 0.3 W
Combined power (+5Vsb): 3 W
Max output current (+5V): 20 A
Operational conditions
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 10 - 40 °C
Operating relative humidity (H-H): 20 - 85%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Depth: 160 mm
Height: 86 mm
Weight: 1.56 kg
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
Packaging data
Package type: Box
Package height: 107 mm
Package width: 229 mm
Package depth: 331 mm
Package weight: 2.76 kg
Packaging content
Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Certificates
Compliance certificates: CCC, EAC, RoHS, CE, Federal Communications Commission (FCC), TÜV mark
Ports & interfaces
Peripheral (Molex) power connectors (4-pin): 3
PCI Express power connectors (6+2 pin): 6
Cabling type: Fully-Modular
Peripheral (Molex) power cable length: 450 mm, 120 mm
CPU power cable length: 65 cm
Number of SATA power connectors: 8
PCI Express connector: Yes
PCI Express power cable length: 60 cm
Motherboard power cable length: 61 cm
Motherboard power connector: 20+4 pin ATX
SATA power cable length: 450, 120
Number of PATA power connectors: 3
CPU power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
Logistics data
Warranty period: 5 year(s)
