Design
Fan diameter: 12 cm
Number of fans: 1 fan(s)
On/off switch: Yes
Fan location: Top
Cooling type: Active
Product colour: Black
Power
Combined power (+3.3V): 100 W
Efficiency: 91%
Max output current (+12V): 62.5 A
Max output current (+3.3V): 20 A
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Combined power (+5V): 100 W
Combined power (+5Vsb): 15 W
Power protection features: Overheating, Under voltage, Over current, Short circuit, Over voltage, Over power
Combined power (-12V): 3.6 W
Combined power (+12V): 750 W
Max output current (+5V): 20 A
Total power: 750 W
Input current: 10-5 A
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): 10 - 40 °C
Operating relative humidity (H-H): 20 - 85%
Weight & dimensions
Depth: 140 mm
Height: 56 mm
Width: 150 mm
Weight: 2.12 kg
Performance
ATX version: 3.1
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Packaging data
Package height: 107 mm
Package type: Box
Package weight: 2.14 kg
Package width: 215 mm
Package depth: 330 mm
Certificates
Compliance certificates: RoHS, CE, EAC, Federal Communications Commission (FCC), UKCA
Ports & interfaces
CPU power connector (4+4 pin): Yes
Motherboard power connector: 20+4 pin ATX
PCI Express connector: Yes
Motherboard power cable length: 61 cm
CPU power cable length: 70 cm
Number of SATA power connectors: 8
Cabling type: Fully-Modular
SATA power cable length: 640, 520, 760 mm, 400 mm
PCI Express power connectors (6+2 pin): 3
Number of PATA power connectors: 3
PCI Express power connectors (12+4 pin) cable length: 650 mm
PCI Express power connectors (12+4 pin): 1
