Design
Number of fans: 1 fan(s)
Fan diameter: 13.5 cm
Cooling type: Active
Fan location: Top
Product colour: Black
On/off switch: Yes
Power
Power protection features: Overheating, Short circuit, Over voltage, Under voltage, Over current, Over power
Combined power (+5V): 120 W
Max output current (+3.3V): 20 A
AC input frequency: 50/60 Hz
Efficiency: 91%
Combined power (+12V): 1000 W
Total power: 1000 W
Combined power (-12V): 3.6 W
Max output current (+12V): 83.3 A
Input current: 15-7.5 A
AC input voltage: 100 - 240 V
Combined power (+3.3V): 120 W
Combined power (+5Vsb): 15 W
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Max output current (+5V): 20 A
Operational conditions
Operating relative humidity (H-H): 20 - 85%
Operating temperature (T-T): 10 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Depth: 150 mm
Width: 150 mm
Weight: 2.65 kg
Height: 86 mm
Performance
Purpose: PC
Mean time between failures (MTBF): 100000 h
80 PLUS certification: 80 PLUS Gold
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
ATX version: 3.1
Packaging data
Package weight: 3.85 kg
Package type: Box
Package height: 107 mm
Package width: 220 mm
Package depth: 316 mm
Certificates
Compliance certificates: RoHS, CE, CCC, Federal Communications Commission (FCC), UKCA, EAC
Ports & interfaces
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 650 mm
Motherboard power cable length: 60 cm
Cabling type: Fully-Modular
Peripheral (Molex) power connectors (4-pin): 4
PCI Express power connectors (6+2 pin): 6
SATA power cable length: 650, 500, 950, 800 mm
PCI Express connector: Yes
Number of SATA power connectors: 12
CPU power cable length: 65 cm
Motherboard power connector: 20+4 pin ATX
PCI Express power cable length: 65 cm
CPU power connector (4+4 pin): Yes
