Design
Fan location: Top
On/off switch: Yes
Product colour: Black
Cooling type: Active
Fan diameter: 13.5 cm
Number of fans: 1 fan(s)
Power
Combined power (+5Vsb): 15 W
Combined power (+12V): 1200 W
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Efficiency: 91%
Max output current (+5V): 20 A
Combined power (+3.3V): 120 W
Combined power (+5V): 120 W
Combined power (-12V): 3.6 W
Max output current (+12V): 100 A
Max output current (+3.3V): 20 A
Power protection features: Over power, Short circuit, Over voltage, Overheating, Under voltage, Over current
AC input frequency: 50/60 Hz
Total power: 1200 W
AC input voltage: 100 - 240 V
Input current: 15-7.5 A
Operational conditions
Operating temperature (T-T): 10 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 20 - 85%
Weight & dimensions
Weight: 2.69 kg
Height: 86 mm
Width: 150 mm
Depth: 150 mm
Performance
Mean time between failures (MTBF): 100000 h
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
Purpose: PC
80 PLUS certification: 80 PLUS Gold
Packaging data
Package weight: 3.89 kg
Package width: 220 mm
Package height: 107 mm
Package type: Box
Package depth: 316 mm
Certificates
Compliance certificates: EAC, CCC, UKCA, RoHS, CE, Federal Communications Commission (FCC)
Ports & interfaces
PCI Express power connectors (12+4 pin): 1
PCI Express power connectors (12+4 pin) cable length: 650 mm
PCI Express power cable length: 65 cm
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 12
Motherboard power connector: 20+4 pin ATX
CPU power cable length: 65 cm
Cabling type: Fully-Modular
PCI Express power connectors (6+2 pin): 6
PCI Express connector: Yes
SATA power cable length: 500, 650, 950, 800 mm
Motherboard power cable length: 60 cm
Peripheral (Molex) power connectors (4-pin): 4
