Design Number of fans: 1 fan(s) Fan diameter: 12 cm On/off switch: Yes Cooling type: Active Product colour: Black
Power Efficiency: 91% Power protection features: Overheating, Over current, Short circuit, Over voltage, Under total voltage, Over power Total power: 1000 W AC input frequency: 50/60 Hz AC input voltage: 100 - 240 V Input current: 15-8 A Combined power (+3.3V): 100 W Max output current (+12V): 83.3 A Combined power (+5V): 100 W Max output current (+3.3V): 20 A Max output current (-12V): 0.4 A Max output current (+5Vsb): 3 A Combined power (+12V): 999.6 W Combined power (-12V): 4.8 W Max output current (+5V): 20 A Combined power (+5Vsb): 15 W
Weight & dimensions Depth: 150 mm Height: 86 mm Width: 150 mm Weight: 2.25 kg
Performance Purpose: PC Power supply unit (PSU) form factor: ATX Mean time between failures (MTBF): 100000 h 80 PLUS certification: 80 PLUS Gold ATX version: 3.1 Bearing technology: FDB
Packaging data Package weight: 3.45 kg Package depth: 220 mm Package height: 107 mm Package width: 316 mm
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 3 PCI Express power connectors (6+2 pin): 3 Cabling type: Fully-Modular PCI Express power connectors (12+4 pin): 1 PCI Express power connectors (12+4 pin) cable length: 600 mm Motherboard power connector: 20+4 pin ATX CPU power connector (4+4 pin): Yes Motherboard power cable length: 60 cm Number of SATA power connectors: 9 SATA power cable length: 450, 150 CPU power cable length: 70 cm
