Design Fan diameter: 12 cm Number of fans: 1 fan(s) On/off switch: Yes Cooling type: Active Product colour: Black
Power Combined power (+5V): 100 W Max output current (+3.3V): 20 A Power protection features: Overheating, Short circuit, Over voltage, Under total voltage, Over power, Over current Combined power (-12V): 3.6 W Total power: 750 W Max output current (-12V): 0.3 A Max output current (+5Vsb): 3 A AC input voltage: 100 - 240 V Combined power (+12V): 750 W Input current: 10 A AC input frequency: 50/60 Hz Max output current (+5V): 20 A Combined power (+5Vsb): 15 W Efficiency: 91% Combined power (+3.3V): 100 W Max output current (+12V): 62.5 A
Weight & dimensions Width: 140 mm Depth: 150 mm Height: 86 mm Weight: 2.2 kg
Performance 80 PLUS certification: 80 PLUS Gold Bearing technology: Rifle ATX version: 3.1 Mean time between failures (MTBF): 100000 h Purpose: PC Power supply unit (PSU) form factor: ATX
Packaging data Package weight: 2.55 kg Package width: 305 mm Package height: 105 mm Package depth: 210 mm
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 PCI Express power connectors (6+2 pin): 2 Cabling type: Fully-Modular CPU power cable length: 70 cm SATA power cable length: 450, 150 PCI Express power connectors (12+4 pin): 1 Motherboard power cable length: 55 cm PCI Express power connectors (12+4 pin) cable length: 600 mm Motherboard power connector: 20+4 pin ATX Number of SATA power connectors: 6 CPU power connector (4+4 pin): Yes
