Design
Fan diameter: 12 cm
Cooling type: Active
Product colour: Black
Number of fans: 1 fan(s)
On/off switch: Yes
Power
Combined power (+12V): 750 W
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Max output current (+12V): 62.5 A
Combined power (+3.3V): 120 W
Efficiency: 91%
Combined power (-12V): 3.6 W
Combined power (+5V): 120 W
Max output current (+3.3V): 20 A
Combined power (+5Vsb): 15 W
Total power: 750 W
Max output current (+5V): 20 A
Power protection features: Short circuit, Over voltage, Overheating, Under voltage, Over current, Over power
AC input voltage: 100 - 240 V
Input current: 10 - 5 A
AC input frequency: 50/60 Hz
Operational conditions
Operating temperature (T-T): 10 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 20 - 85%
Weight & dimensions
Weight: 2.01 kg
Height: 86 mm
Width: 150 mm
Depth: 140 mm
Performance
Bearing technology: HDB
Power supply unit (PSU) form factor: ATX
Purpose: PC
ATX version: 3.1
80 PLUS certification: 80 PLUS Gold
Packaging data
Package width: 215 mm
Package weight: 2.81 kg
Package height: 105 mm
Package depth: 290 mm
Certificates
Compliance certificates: TÜV mark, UKCA, RoHS, CE, Federal Communications Commission (FCC), EAC
Ports & interfaces
PCI Express power connectors (12+4 pin) cable length: 600 mm
PCI Express power connectors (6+2 pin): 4
PCI Express power cable length: 55 cm
PCI Express power connectors (12+4 pin): 1
CPU power cable length: 60 cm
CPU power connector (4+4 pin): Yes
Number of SATA power connectors: 6
Peripheral (Molex) power cable length: 450 mm, 150
SATA power cable length: 450, 150
Motherboard power cable length: 55 cm
Cabling type: Non-Modular
PCI Express connector: Yes
Motherboard power connector: 20+4 pin ATX
Peripheral (Molex) power connectors (4-pin): 3
