Design
On/off switch: Yes
Cooling type: Active
Number of fans: 1 fan(s)
Product colour: Black
Fan diameter: 12 cm
Power
AC input frequency: 50/60 Hz
Power protection features: Under voltage, Over current, Overheating, Short circuit, Over voltage, Over power
AC input voltage: 100 - 240 V
Input current: 12 - 6 A
Max output current (+3.3V): 20 A
Combined power (+5Vsb): 15 W
Combined power (+5V): 120 W
Combined power (-12V): 3.6 W
Combined power (+12V): 850 W
Total power: 850 W
Max output current (+5V): 20 A
Efficiency: 91%
Max output current (+5Vsb): 3 A
Max output current (-12V): 0.3 A
Combined power (+3.3V): 120 W
Max output current (+12V): 70.8 A
Operational conditions
Operating relative humidity (H-H): 20 - 85%
Operating temperature (T-T): 10 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Weight & dimensions
Depth: 140 mm
Weight: 2.22 kg
Height: 86 mm
Width: 150 mm
Performance
80 PLUS certification: 80 PLUS Gold
ATX version: 3.1
Power supply unit (PSU) form factor: ATX
Bearing technology: HDB
Purpose: PC
Packaging data
Package weight: 3.02 kg
Package width: 215 mm
Package height: 105 mm
Package depth: 290 mm
Certificates
Compliance certificates: UKCA, Federal Communications Commission (FCC), TÜV mark, RoHS, CE, EAC
Ports & interfaces
PCI Express power connectors (12+4 pin) cable length: 600 mm
PCI Express power connectors (12+4 pin): 1
Peripheral (Molex) power connectors (4-pin): 4
PCI Express connector: Yes
Cabling type: Non-Modular
PCI Express power cable length: 55 cm
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Motherboard power cable length: 55 cm
Peripheral (Molex) power cable length: 150, 450 mm
Number of SATA power connectors: 8
PCI Express power connectors (6+2 pin): 4
CPU power cable length: 60 cm
SATA power cable length: 150, 450
