Design Cooling type: Active Number of fans: 1 fan(s) Fan diameter: 12 cm Product colour: Black
Power AC input frequency: 50 Hz Combined power (+12V): 456 W Combined power (+5V): 110 W Power protection features: Under voltage, Over current, Over power, Short circuit, Over voltage Combined power (+5Vsb): 2.5 W Max output current (+3.3V): 16 A Max output current (+12V): 42 A Power Factor Correction (PFC) type: Active Total power: 500 W Combined power (-12V): 0.3 W Combined power (+3.3V): 110 W AC input voltage: 220 - 240 V
Weight & dimensions Width: 150 mm Depth: 140 mm Height: 86 mm Weight: 1.48 kg
Performance Purpose: PC/Server 80 PLUS certification: 80 PLUS
Packaging data Package width: 158 mm Package height: 165 mm Package weight: 1.76 kg Package depth: 187 mm
Ports & interfaces Motherboard power connector: 20+4 pin ATX Motherboard power cable length: 45 cm Number of PATA power connectors: 2 Cabling type: Non-Modular Peripheral (Molex) power cable length: 450 Number of SATA power connectors: 5 PCI Express power connectors (6+2 pin): 2
Other features Commodity Classification Automated Tracking System (CCATS): 8504401300
