Design Number of fans: 1 fan(s) Cooling type: Active Product colour: Black Fan diameter: 12 cm
Power AC input frequency: 50 Hz AC input voltage: 200 - 240 V Input current: 5 A Power protection features: Short circuit, Over voltage, Over power, Under voltage, Over current Total power: 600 W Max output current (+3.3V): 18 A Max output current (+12V): 49 A Max output current (+5V): 20 A Combined power (+5V): 130 W Max output current (-12V): 0.3 A Combined power (+3.3V): 130 W Power Factor Correction (PFC) type: Active Max output current (+5Vsb): 3 A Combined power (+12V): 588 W
Weight & dimensions Depth: 150 mm Weight: 1.52 kg Width: 140 mm Height: 86 mm
Performance 80 PLUS certification: 80 PLUS Purpose: PC
Packaging data Package height: 165 mm Package width: 187 mm Package weight: 1.8 kg Package depth: 158 mm
Certificates Compliance certificates: EAC, RoHS, CE
Ports & interfaces Peripheral (Molex) power connectors (4-pin): 2 Motherboard power cable length: 45 cm Number of PATA power connectors: 2 SATA power cable length: 450 Peripheral (Molex) power cable length: 450 CPU power connector (4+4 pin): Yes PCI Express power connectors (6+2 pin): 2 Number of SATA power connectors: 6 CPU power cable length: 65 cm Motherboard power connector: 20+4 pin ATX
Other features Commodity Classification Automated Tracking System (CCATS): 8504401300
