Design Product colour: Black Illumination LED: Yes Radiator material: Aluminum Number of fans: 2 fan(s) Fan connector: 4-pin Base plate material: Copper Illumination colour: Multi LED connector type: 3-pin
Power Fan voltage: 12 V Fan current: 0.17 A Pump current: 350 mA LED voltage: 5 V Pump voltage: 12 V
Weight & dimensions Package weight: 2.3 kg Weight: 1.76 kg Cable length: 0.04 m Pump width: 9.1 cm Radiator depth: 31.7 cm Package height: 155 mm Tube length: 45 cm Pump height: 6.85 cm Radiator width: 13.8 cm Package width: 170 mm Radiator height: 3.8 cm Tube diameter: 1.24 cm Pump depth: 10.8 cm Package depth: 355 mm Fan dimensions (W x D x H): 140 x 140 x 27 mm Tube inner diameter: 6 mm
Performance Supported processor sockets: Socket AM4, LGA 1700, LGA 1851, Socket AM5 Operating temperature (T-T): 0 - 40 °C Type: All-in-one liquid cooler Maximum airflow: 69.9 cfm Quantity per pack: 1 pc(s) Pump motor speed (min): 800 RPM Fan static pressure: 2 mmH2O Bearing type: Fluid Dynamic Bearing (FDB) Airflow: 117.06 m³/h Suitable location: Processor Fan speed (min): 200 RPM Fan diameter: 14 cm Pulse-width modulation (PWM) support: Yes Fan speed (max): 1900 RPM Pump motor speed (max): 2800 RPM Pump connector: 4-pin VRM fan speed (max): 2500 RPM VRM fan speed (min): 400 RPM
Packaging content Package type: Hanging box
Safety warning Warnings: Take appropriate precautions during installation to avoid damage to computer components., Do not touch the fan during operation., Ensure that the unit is switched off before starting to assemble or dismantle the cooling unit.
