Technical details
Compliance certificates: Federal Communications Commission (FCC), CE
Design
Internal: Yes
Component for: PC
LED indicators: Speed, Link, Activity
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 65 °C
Weight & dimensions
Width: 100 mm
Depth: 66 mm
Weight: 84.5 g
Height: 15 mm
Network
Maximum data transfer rate: 10000 Mbit/s
Networking standards: IEEE 802.3an, IEEE 802.3az, IEEE 802.3x, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab
Ethernet interface type: Fast Ethernet, 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet, 5 Gigabit Ethernet
Ethernet LAN data rates: 1000 Mbit/s, 2500, 10, 10000 Mbit/s, 100
Ethernet LAN: Yes
System requirements
Server operating systems supported: Windows Server 2022
Linux operating systems supported: Yes
Windows operating systems supported: Windows 11, Windows 10
Packaging content
Quick installation guide: Yes
Mounting brackets included: Yes
Cables included: LAN (RJ-45)
Ports & interfaces
Host interface: PCI Express
Connectivity technology: Wired
Interface: Ethernet
PCI version: 3.0
Ethernet LAN (RJ-45) ports: 1
