Design
LED indicators: Yes
Product colour: Black
Wall mountable: Yes
Reset button: Yes
Housing material: Aluminium
International Protection (IP) code: IP40
DIN rail mounting: Yes
Power
Surge protection: Yes
Power source: DC
Power supply included: No
DC input voltage: 48 - 57 V
Power consumption (max): 3 W
Redundant power supply (RPS) support: Yes
Surge protection voltage: 4 kV
Operational conditions
Operating relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -40 - 85 °C
Storage temperature (T-T): -40 - 85 °C
Management features
Switch type: Unmanaged
Weight & dimensions
Depth: 103 mm
Width: 143.7 mm
Height: 47.7 mm
Weight: 520 g
Network
Full duplex: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto MDI/MDI-X: Yes
Copper ethernet cabling technology: 1000BASE-TX, 10BASE-T, 100BASE-TX
Networking standards: IEEE 802.3x, IEEE 802.3z, IEEE 802.3u, IEEE 802.3i, IEEE 802.3, IEEE 802.3ab
10G support: No
Cable types supported: Cat6, Cat5, Cat4, Cat3
Half duplex: Yes
Performance
Mean time between failures (MTBF): 300000 h
Packaging data
Package weight: 620 g
Certificates
Compliance certificates: CE
Protocols
Supported network protocols: IEEE802.3 10BASE-T; IEEE802.3i 10Base-T; IEEE802.3u 100Base-TX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE802.3x
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 8
Data transmission
Packet buffer memory: 1 MB
MAC address table: 2000 entries
Switching capacity: 1.6 Gbit/s
Forwarding rate: 1.2 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 240 W
Power over Ethernet (PoE) power per port: 30 W
Power over Ethernet (PoE) type supported: PoE+
Optical fiber
Maximum transfer distance (Single-mode): 100 m
Transmission distance (max): 10 km
Sustainability
Sustainability compliance: Yes
