Technical details
Products per shipping (inner) case: 10 pc(s)
Features
Networking standards: IEEE 802.3at, IEEE 802.11be, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.3af
Bluetooth: No
Ethernet LAN data rates: 100, 2500 Mbit/s, 10, 1000
MIMO: Yes
Quality of Service (QoS) support: Yes
5 GHz: Yes
2.4 GHz: Yes
Maximum data transfer rate: 2882 Mbit/s
MIMO type: Multi User MIMO
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
VLAN support: Yes
Maximum data transfer rate (5 GHz): 2882 Mbit/s
6 GHz: No
Design
LED indicators: System
Product colour: White
Reset button: Yes
Placement: Ceiling, Wall
Power
Power over Ethernet (PoE): Yes
DC voltage range: 48-57 V
Power consumption (max): 10 W
Power over Ethernet (PoE) type supported: Passive PoE
Output voltage: 12 V
Output current: 1 A
Security
Security algorithms: WPA2, WPA, WPA3
IGMP snooping: Yes
Guest access: Yes
Number of SSID supported: 8
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 95%
Management features
Syslog: Yes
Cloud-managed: Yes
Weight & dimensions
Weight: 435 g
Height: 57.1 mm
Depth: 231.9 mm
Width: 231.9 mm
Performance
Processor frequency: 2000 MHz
Internal memory: 512 MB
Built-in processor: Yes
Flash memory: 128 MB
Packaging data
Package weight: 843 g
Package width: 310 mm
Package depth: 238 mm
Package height: 73 mm
Bundled software: Cudy Software
Packaging content
AC adapter included: No
Mounting kit: Yes
Quick start guide: Yes
PoE adapter included: No
Cables included: LAN (RJ-45)
Certificates
Compliance certificates: Federal Communications Commission (FCC), CE
Protocols
DHCP server: Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 2
DC-in jack: Yes
Antenna
Antenna type: Internal
Antenna gain level (max): 5.5 dBi
Antennas quantity: 4
Logistics data
Country of origin: China
