Design
LED indicators: Yes
Wall mountable: Yes
Rack mounting: Yes
Product colour: Black
Power
Power consumption (typical): 30 W
AC input voltage: 100 - 240 V
Power supply included: Yes
Power source: AC/DC
AC input frequency: 50 - 60 Hz
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -10 - 50 °C
Storage relative humidity (H-H): 5 - 95%
Operating relative humidity (H-H): 10 - 90%
Management features
Switch type: Unmanaged
Weight & dimensions
Height: 44 mm
Width: 260 mm
Depth: 161 mm
Weight: 880 g
Network
Cable types supported: Cat3, Cat4, Cat5
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-TX
Networking standards: IEEE 802.3u, IEEE 802.3x, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af
10G support: No
Flow control support: Yes
Performance
Mean time between failures (MTBF): 100000 h
Packaging data
Package width: 315 mm
Package height: 85 mm
Package weight: 1.38 kg
Package type: Box
Package depth: 215 mm
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 8
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
SFP module slots quantity: 2
Data transmission
MAC address table: 2000 entries
Jumbo frames: 9216
Forwarding rate: 14.88 Mpps
Store-and-forward: Yes
Switching capacity: 20 Gbit/s
Jumbo frames support: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Optical fiber
Fiber type: Multi-mode
