Design
Rack mounting: Yes
Housing material: Metal
Product colour: Black
LED indicators: Activity, Link, Power
Airflow direction: Side-to-side airflow
Power
Power source: AC
Power supply included: Yes
AC input frequency: 50 - 60 Hz
Output voltage: 52 V
AC input voltage: 100 - 240 V
Output current: 3.85 A
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 95%
Operating temperature (T-T): -20 - 50 °C
Storage temperature (T-T): -40 - 80 °C
Operating altitude: 0 - 3000 m
Network
Cable types supported: Cat6+, Cat8, Cat6, Cat8.1, Cat5, Cat5e, Cat6e, Cat7e, Cat6a, Cat7
Networking standards: IEEE 802.3af, IEEE 802.3z, IEEE 802.3u, IEEE 802.3x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at
Copper ethernet cabling technology: 100BASE-TX, 10BASE-T, 1000BASE-TX
VLAN support: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto-sensing: Yes
Performance
Mean time between failures (MTBF): 50000 h
Packaging content
Cables included: AC
Rack mount kit: Yes
Ports & interfaces
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 16
Power connector: AC-in jack
Combo SFP ports quantity: 2
Fiber uplink ports quantity: 2
Other features
Bandwidth: 52 Gbit/s
Data transmission
MAC address table: 8000 entries
Packet buffer memory: 4 MB
Forwarding rate: 38.7 Mpps
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port: 30 W
Total Power over Ethernet (PoE) budget: 200 W
Power over Ethernet (PoE): Yes
Power over Ethernet plus (PoE+) ports quantity: 16
Power over Ethernet (PoE) ports quantity: 16
Optical fiber
Switching optical modules type: Gigabit Ethernet
Fiber type: Multi-mode
Transmission distance (max): 120 km
Maximum transfer distance (Single-mode): 120000 m
Maximum transfer distance (Multi-mode): 2000 m
