Design
LED indicators: Power, Link, Activity
Product colour: Black
Rack mounting: No
Power
DC input voltage: 5 V
Power supply included: Yes
Input current: 0.5 A
Power source: DC
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage relative humidity (H-H): 5 - 95%
Weight & dimensions
Width: 100 mm
Height: 27 mm
Weight: 135 g
Depth: 74 mm
Network
Half duplex: Yes
Full duplex: Yes
Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3u
Ethernet LAN data rates: 10,100,1000 Mbit/s
Auto-negotiation: Yes
Auto MDI/MDI-X: Yes
MAC address auto-aging supported: Yes
Copper ethernet cabling technology: 10BASE-TX, 100BASE-TX
MAC address auto-learning supported: Yes
Performance
Plug and Play: Yes
Packaging data
Cables included: DC
Manual: Yes
Package type: Box
Protocols
Switching protocols: CSMA/CD
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 5
Other features
Bandwidth: 1 Gbit/s
Data transmission
MAC address table: 2000 entries
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): No
