Design
Stackable: Yes
LED indicators: Power, Link, Activity, System
Rack mounting: Yes
Product colour: Black
Form factor: 1U
Power
Power supply included: Yes
AC input voltage: 100 - 240 V
Power source: AC
Security
IP-MAC-Port binding: Yes
Authentication type: RADIUS, TACACS+
Authentication: Port-based authentication
SSH/SSL support: Yes
IGMP snooping: Yes
DHCP features: DHCP server, DHCP Option 82, DHCP snooping
Operational conditions
Storage relative humidity (H-H): 5 - 90%
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -10 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Management features
Switch type: Managed
Traffic classification: Yes
System event log: Yes
Web-based management: Yes
Switch layer: L2
Quality of Service (QoS) support: Yes
Weight & dimensions
Weight: 1.01 kg
Depth: 181 mm
Height: 44 mm
Width: 268 mm
Network
Link aggregation: Yes
Spanning tree protocol: Yes
Networking standards: IEEE 802.1Qav, IEEE 802.11j, IEEE 802.11k
Broadcast storm control: Yes
Cable types supported: Cat5, Cat3, Cat4
Ethernet LAN data rates: 10,100,1000 Mbit/s
MAC address auto-aging supported: Yes
MAC address auto-learning supported: Yes
Rate limiting: Yes
Virtual LAN features: Voice VLAN
Number of VLANs: 4096
Flow control support: Yes
Port mirroring: Yes
VLAN support: Yes
Performance
Memory type: DDR-SDRAM
Flash memory: 16 MB
Internal memory: 128 MB
Packaging data
Package height: 84 mm
Package weight: 1.54 kg
Package type: Box
Package depth: 262 mm
Package width: 312 mm
Protocols
IPv4 & IPv6 features: IPv6 Telnet
Ports & interfaces
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity: 8
Console port: RJ-45
Installed SFP modules quantity: 2
Basic switching RJ-45 Ethernet ports quantity: 8
Data transmission
Switching capacity: 56 Gbit/s
MAC address table: 8000 entries
Static route: Yes
Forwarding rate: 41.66 Mpps
Jumbo frames support: Yes
Jumbo frames: 9.6
Packet buffer memory: 0.5 MB
Multicast features
Multicast support: Yes
Optical fiber
Fiber type: Multi-mode
