Design
Form factor: 1U
LED indicators: Power, Link, System, Activity
Product colour: Black
Stackable: Yes
Rack mounting: Yes
Power
AC input voltage: 100 - 240 V
Power supply included: Yes
Power source: AC
Security
DHCP features: DHCP snooping, DHCP Option 82, DHCP server
Authentication: Port-based authentication
SSH/SSL support: Yes
Authentication type: AAA, TACACS+
IP-MAC-Port binding: Yes
IGMP snooping: Yes
Operational conditions
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): -10 - 50 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management features
Switch type: Managed
Quality of Service (QoS) support: Yes
Switch layer: L2/L3
System event log: Yes
Traffic classification: Yes
Web-based management: Yes
Weight & dimensions
Height: 44 mm
Depth: 204 mm
Weight: 2.45 kg
Width: 440 mm
Network
MAC address auto-aging supported: Yes
Number of VLANs: 4096
Flow control support: Yes
Port mirroring: Yes
Ethernet LAN data rates: 10,100,1000 Mbit/s
IP routing: Yes
Networking standards: IEEE 802.11j, IEEE 802.1Qav, IEEE 802.11k
VLAN support: Yes
MAC address auto-learning supported: Yes
Virtual LAN features: Voice VLAN
Link aggregation: Yes
Broadcast storm control: Yes
Cable types supported: Cat3, Cat5, Cat4
Rate limiting: Yes
Spanning tree protocol: Yes
Performance
Memory type: DDR-SDRAM
Internal memory: 128 MB
Flash memory: 16 MB
Packaging data
Package weight: 3.06 kg
Package width: 500 mm
Package depth: 290 mm
Package height: 85 mm
Package type: Box
Protocols
IPv4 & IPv6 features: IPv6 Telnet
Ports & interfaces
Installed SFP modules quantity: 4
Console port: RJ-45
Gigabit Ethernet (copper) ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 24
Data transmission
Jumbo frames support: Yes
Jumbo frames: 9.6
Forwarding rate: 14.88 Mpps
Switching capacity: 20 Gbit/s
Static route: Yes
MAC address table: 8000 entries
Packet buffer memory: 0.5 MB
Multicast features
Multicast support: Yes
Optical fiber
Fiber type: Multi-mode
