Design
LED indicators: Power, System, Activity, Link
Product colour: Black
Form factor: 1U
Rack mounting: Yes
Housing material: Metal
Power
AC input voltage: 100 - 240 V
Surge protection: Yes
Power source: AC
Surge protection voltage: 15 kV
DC input voltage: 52 V
Security
IGMP snooping: Yes
Access Control List (ACL): Yes
IP-MAC-Port binding: Yes
Queue scheduling algorithms: Strict Priority Queue (SPQ), Weighted Round Robin (WRR)
Authentication type: IEEE 802.1x, TACACS+
Authentication: Port-based authentication
SSH/SSL support: Yes
Operational conditions
Operating altitude: 0 - 3048 m
Storage temperature (T-T): -40 - 85 °C
Operating temperature (T-T): -20 - 55 °C
Operating relative humidity (H-H): 10 - 95%
Non-operating altitude: 0 - 3048 m
Management features
Quality of Service (QoS) support: Yes
Web-based management: Yes
Switch type: Managed
Switch layer: L2
System event log: Yes
Weight & dimensions
Width: 285 mm
Depth: 445 mm
Height: 45 mm
Network
Networking standards: IEEE 802.3af, IEEE 802.3az, IEEE 802.3, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3u, IEEE 802.3ad, IEEE 802.1Q, IEEE 802.3x
10G support: No
Cable length detection: Yes
Flow control support: Yes
Number of VLANs: 4096
Copper ethernet cabling technology: 100BASE-TX, 1000BASE-TX, 10BASE-T
VLAN support: Yes
Port mirroring: Yes
Rate limiting: Yes
Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6
Virtual LAN features: MAC address-based VLAN, Voice VLAN
MAC address auto-learning supported: Yes
Link aggregation: Yes
MAC address auto-aging supported: Yes
Spanning tree protocol: Yes
Broadcast storm control: Yes
Performance
Internal memory: 128 MB
Flash memory: 16 MB
Fanless: Yes
Packaging data
Package depth: 470 mm
Package height: 120 mm
Package width: 350 mm
Protocols
GARP VLAN Registration Protocol (GVRP): Yes
Management protocols: SSHv1/2, SNMP V1/V2/V3, RMON v1
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Combo SFP ports quantity: 4
Console port: RJ-45
Uplink ports quantity: 4
Gigabit Ethernet (copper) ports quantity: 24
Data transmission
MAC address table: 8000 entries
Switching capacity: 56 Gbit/s
Packet buffer memory: 4 MB
Forwarding rate: 41.66 Mpps
Store-and-forward: Yes
Power over Ethernet (PoE)
Power over Ethernet (PoE): Yes
Total Power over Ethernet (PoE) budget: 300 W
Power over Ethernet (PoE) voltage: 55 V
Power over Ethernet (PoE) power per port: 30 W
Multicast features
Multicast support: Yes
Multicast features: Multicast traffic suppression
Multicast Listener Discovery (MLD) snooping: v1/2/3
Optical fiber
Wavelength: 1550 nm
Fiber type: Multi-mode
Transmission distance (max): 120 km
Maximum transfer distance (Single-mode): 120000 m
Maximum transfer distance (Multi-mode): 2000 m
