Features
Flash memory: 16 MB
Internal memory: 128 MB
Design
LED indicators: System, WLAN
Product colour: White
Product type: Desktop/pole router
Wall mountable: Yes
International Protection (IP) code: IP65
Power
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Power source type: PoE
Output voltage: 24 V
External power adapter: Yes
Security
Filtering: Yes
Security algorithms: WPA, WPA2, WPA3
MAC address filtering: Yes
Firewall: Yes
IP address filtering: Yes
IGMP snooping: Yes
URL filtering: Yes
DMZ support: Yes
Operational conditions
Operating temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 100%
Storage relative humidity (H-H): 5 - 95%
Storage temperature (T-T): -40 - 70 °C
Management features
Reset button: Yes
Wake-on-LAN ready: Yes
MIMO: Yes
Wi-Fi Multimedia (WMM)/(WME): Yes
MU-MIMO technology: Yes
Weight & dimensions
Weight: 420 g
Height: 53.7 mm
Width: 240 mm
Depth: 100 mm
VPN support: PPTP/L2TP/OpenVPN/WireGuard/IPSec/Zerotier
Network
Ethernet LAN data rates: 100, 10
Ethernet LAN interface type: Fast Ethernet
Port forwarding: Yes
Port triggering: Yes
Ethernet LAN: Yes
Dynamic DNS (DDNS): Yes
Number of guest networks (5 GHz): 1
Number of guest networks (2.4 GHz): 1
System requirements
Windows operating systems supported: Windows 7 Home Premium x64, Windows 7 Enterprise x64, Windows 11, Windows Vista Business, Windows 8.1, Windows Vista Ultimate, Windows 7 Ultimate x64, Windows Vista, Windows 7 x64, Windows 10, Windows Vista Ultimate x64, Windows 10 IOT Core, Windows 8 Enterprise x64, Windows 8 Pro, Windows 7 Enterprise, Windows Vista Enterprise, Windows 8.1 Enterprise, Windows 7 Professional, Windows 7, Windows XP Professional x64, Windows Vista Home Premium x64, Windows 10 Education x64, Windows XP Home x64, Windows Vista Home Basic x64, Windows 7 Professional x64, Windows 11 Enterprise, Windows 10 Pro x64, Windows 8 Enterprise, Windows 8 Pro x64, Windows 8.1 Pro, Windows 10 Pro, Windows 7 Home Premium, Windows 7 Starter, Windows 10 IoT Enterprise, Windows Vista Enterprise x64, Windows 8.1 Enterprise x64, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Home Basic, Windows 10 Home x64, Windows 8, Windows 7 Home Basic, Windows 7 Ultimate, Windows 2000, Windows 8 x64, Windows Vista Business x64, Windows 10 Education, Windows XP Professional, Windows XP, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 98SE, Windows Vista Home Premium, Windows XP Home, Windows 10 Home, Windows 7 Starter x64, Windows 10 Enterprise x64, Windows 10 x64
Mac operating systems supported: Yes
Linux operating systems supported: Yes
Packaging data
Package width: 324 mm
Package weight: 785 g
Package height: 86 mm
Package depth: 107 mm
Packaging content
Mounting kit: Yes
Quick installation guide: Yes
PoE injector included: Yes
Cables included: LAN (RJ-45)
Wireless LAN features
Modulation: 256-QAM
WLAN data transfer rate (first band): 300 Mbit/s
Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a
WLAN data transfer rate (second band): 867 Mbit/s
WLAN data transfer rate (max): 867 Mbit/s
Protocols
DHCP client: Yes
Supported network protocols: IPv4 / IPv6
Universal Plug and Play (UPnP): Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports: 1
USB port: No
Antenna
Antennas quantity: 4
Antenna design: Internal & external
Detachable antenna(s): Yes
WAN connection
Ethernet WAN: Yes
SIM card slot: Yes
WAN connection type: RJ-45
Mobile network
2G standards: Edge, GSM
Dual SIM support: No
Mobile network generation: 4G
SIM card type: NanoSIM
4G standard: LTE-TDD & LTE-FDD
3G standards: WCDMA
Safety warning
Warnings: Avoid contact with liquids as this may cause electric shock., Do not open the appliance housing - risk of electric shock., The product may emit radio waves that may interfere with other electronic devices.
