Design
Internal: Yes
Mean time between failures (MTBF): 376212 h
Component for: PC/Server
LED indicators: Activity, Link, Speed
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -20 - 70 °C
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): -10 - 60 °C
Weight & dimensions
Depth: 50 mm
Height: 1.6 mm
Width: 71.5 mm
Network
LAN controller: Realtek RTL8125
Networking standards: IEEE 802.3bz, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az
Ethernet LAN data rates: 2500, 1000 Mbit/s, 100, 10
Wake-on-LAN ready: Yes
Ethernet interface type: Gigabit Ethernet, 2.5 Gigabit Ethernet, Fast Ethernet
Cabling technology: 10/100/1000BaseT(X)
Ethernet LAN: Yes
Copper ethernet cabling technology: 10BASE-T, 1000BASE-TX
Full duplex: Yes
Auto MDIX IEEE: Yes
Jumbo frames support: Yes
System requirements
Server operating systems supported: Windows Server 2012, Windows Server 2008
Windows operating systems supported: Windows 8, Windows 10, Windows 8.1, Windows 7
Packaging data
Package type: Box
Low-profile bracket: Yes
Packaging content
Quick installation guide: Yes
Mounting brackets included: Yes
Resource CD: Yes
Ports & interfaces
Connectivity technology: Wired
Interface: Ethernet
Ethernet LAN (RJ-45) ports: 1
Host interface: PCI Express
PCI Card form factor: Full-height (low-profile)
Other features
Flow control support: Yes
