Design
Internal: Yes
Antenna direction type: Omni-directional
Component for: PC
Antenna gain level (max): 5 dBi
Antenna design: External
Antenna: Yes
Operational conditions
Storage temperature (T-T): -10 - 80 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 70 °C
Weight & dimensions
Height: 1.6 mm
Width: 65 mm
Depth: 44.5 mm
Network
Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11b, 802.11g
Wi-Fi: Yes
Networking standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11ax, IEEE 802.11g, IEEE 802.11n, IEEE 802.11b
Spread spectrum method: OFDMA
Bluetooth version: 5.2
WLAN data transfer rates supported: 574, 2402
Maximum data transfer rate: 2400 Mbit/s
Security algorithms: WPA3
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Bluetooth: Yes
LAN controller: Intel AX210
System requirements
Windows operating systems supported: Windows 10, Windows 11
Packaging content
Resource CD: Yes
Quick installation guide: Yes
Bluetooth header cable: Yes
Mounting brackets included: Yes
Ports & interfaces
PCI Card form factor: Full-height (low-profile)
Host interface: PCI Express
Interface: WLAN / Bluetooth
Connectivity technology: Wireless
Other features
Bracket height: Low-Profile (LP) / Full-Height (FH)
Safety warning
Warnings: The product contains electronic components and should not be disposed of in the regular rubbish bin., Please observe local regulations regarding the disposal of electronic waste.
